RunCam Split Mini 2

Purchase this product now and earn 69 Points!

USD $69.99

NEW VERSION! PRE-ORDER NOW!!!
RunCam Split Mini V2 is the most compact 1080P/60fps HD recording & WDR FPV camera with ability to record GoPro quality 1080p/60fps HD FPV videos.

RumCam Split Mini V2 features features 20×20 mounting, 4:3 / 16:9 auto adaptation, power-off protection for video files, light weight (just 12.5g), anti-drop SD card protection and low 40ms latency.

In stock

StumbleUpon

Earn 100 points for reviewing this product

SKU: 1217 Categories: ,

Description

RUNCAM SPLIT MINI 2

  • 1080P/60fps HD recording & WDR FPV camera
  • Power-off protection for video files
  • Ultra light weight (12.5g)
  • Low latency TV-OUT (40ms) Wide voltage (5-20V)
  • Anti-drop SD card

MODULAR DESIGN

  • REPLACEABLE LENS
  • MANUAL FOCUS SUPPORTED

EASY INSTALLATION

  • Standard mounting bracket
  • Mounting Dimension:20*20mm
  • Light weight (12.5g)
  • SD card protector

FPV (4:3 / 16:9 auto adaptation)

DIMENSIONS

Specification

  • FOV Angle of Field: FPV FOV 130° / Recording FOV 165°
  • Video Resolution: [email protected] / [email protected] / [email protected] / [email protected]
  • Video Files: MOV
  • Image Resolution: 2 MP
  • TV Output: NTSC (720*480) / PAL (720*576) Switchable
  • Interface: Micro USB / UART
  • Max Micro SD Card Supported: 64G(need Class 6 or above, recommend Class 10/UHS-I/UHS-II)
  • Hole Distance of Installation: 20*20mm
  • Dimensions: PCB 29*29mm / Lens Module 19*19mm
  • Power Input: DC 5-20V
  • Working Current: 650mA @5V / 270mA @12V
  • Weight:

Manual / Wiring Diagram

Download the RunCam Split Mini V2 User Manual (PDF)

Package Includes

  • 1x Camera
  • 1x Micro-to-full-size mounting bracket
  • 1x Metal Cover
  • 1x Set of M2 screws
  • 1x 3PIN 1.25 JST Silicone Cable(female)
  • 1x 3PIN 1.25 JST Silicone Cable(male)
  • 1x 3PIN 1.0 JST Silicone Cable
  • 1x Manual
